Apraksts
https://www.weller-tools.com/eu/de/industrielles-loeten/produkte/loetstationen/wxd-2020
Height 135mm
length 174mm
Dimensions L x W x H 174.0 x 154.0 x 135.0mm
air consumption 35 l/min
air pressure 58 – 87 psi
compressed air connection 6.0mm
compressed air connection accessories Oil free, dry compressed air
desoldering Yes
equipotential bonding socket Via 3.5 mm jack socket on the back of the device.
ESD-safe Yes
backup T2 A
IPC compliant Yes
Noise level (distance 1 m) dB(A) 0.7 bar
number of channels 2
operating pressure 4 – 6 bar 54 – 87 psi
Performance 200 W (255 W)
temperature accuracy °C ±9 °c
temperature accuracy °F ±17 °F
temperature stability °C ±2 °C
temperature stability °F ±4 °C
Tension 230 V
