Apraksts
Connectors
- Connector A: RJ45 Male
- Connector B: RJ45 Male
- Housing Material: Polycarbonate
- Connector Plating: –
- Pin Construction: Copper Alloy
- Pin Plating: Gold plated
- Dimensions (approx.) WxDxH: 11.6×22.8×8.3mm (0.46×0.90×0.33in)
Cable Construction
- Length: 0.5m (1.64ft)
- Colour: Blue
- Type: Cat.6
- Jacket Diameter: 5.8mm (0.23in)
- Jacket Material: PVC
- Conductor Material: CCA
- Conductor Gauge: 26AWG
- Shielding: –
Specifications
- Supported Bandwidth: 250MHz
- Nominal Attenuation: 32.8dB/100m @250MHz
- Minimum Bend Radius: 69mm (2.72in)
- Operating Temperature: -10°C – 60°C (14°F – 140°F)
- Storage Temperature: -20°C – 75°C (-4°F – 167°F)
Miscellaneous
- Packaging Type: Polybag
- Warranty (Years): 10
- Certificated: RoHS, REACH, California Proposition 65
Purchasing Information
- No.: 48171
- EAN: 4002888481717
This product is also available in other lengths:
- 48170 – 0.3m (0.98ft)
- 48171 – 0.5m (1.64ft)
- 48172 – 1m (3.28ft)
- 48173 – 2m (6.56ft)
- 48174 – 3m (9.84ft)
- 48175 – 5m (16.44ft)
- 48176 – 7.5m (24.61ft)
- 48177 – 10m (32.81ft)
