Apraksts
Infrared Image:
IR resolution: 480 x 360
Image Frequency: 30Hz
Detector Pitch: 17 μm
Spectral Range: 7.5 to 14 μm
Focal Lenght L37: 12.6mm
FOV: 37 x 28°
IFOV: 1.35 mrad
Focus Mode: Laser Assisted AF, Continuous AF, AF/Manual Focus, Touch AF
Min. focus distance: 0.15m
SuperIR: Yes, 960 x 720p
Image specification:
Camera: 3264x2448p (8Mp)
Display: 1280×720, 5″ LCD touch screen
Digital Zoom: 1.0 to 12.0x
Image Modes: Thermal, Vsual, Fusion, Picture in Picture, Blending.
Color Palettes: White Hot, Black Hot, Rainbow, Ironbow, Red Hot, Fusion, Rain, Blue Red.
Measurement:
Temperature range: -20 to 650°C
Measuring tools: Center spot, Hot spot, Cold spot
Inspection Route: Yes
Data Storage and file specification:
Storage Media: Memory card 128Gb
Image Storage Capacity: About 120.000 Images
Video Storage Capacity: About 500 hours
Video File Format: MP4 video and Radiometric video
General parameters:
Wi-Fi: Yes, 802.11 (2.4 and 5 GHz)
Bluetooth: Yes, 4.2v
USB interface: USB Type;C
HDMI: HDMI-D
GPS and Compass: Yes
Laser Distance meter: up to 50m
Battery: Rechrgeable Li-ion battery.
Operating time: Appox. 4 hours
Chargung time: 2.5 hours
Power saving: Manual Sleep and Auto Power-off
Protection Level: IP54 and drop test 1m
Stogare temperature: -20°C +60°C
Weight: 1400g
Dimension: 210 x 141 x 88 mm
