Infrared Image:
IR resolution: 256×192
Image Frequency: 25Hz
Detector Pitch: 12 μm
Spectral Range: 7.5 to 14 μm
FOV: 37.2 x 50°
IFOV: 3.3 mrad
Focus Mode: Focus Free
Min. focus distance: 0.3m
SuperIR: Yes, on captured images and live view
Image specification:
Image Modes: Thermal, PIP
Color Palettes: White Hot, Black Hot, Rainbow, Ironbow, Sepia, Color, Ice Fire, Rain, Red Hot, Green Hot, Dark Blue, Combined
Measurement:
Temperature range: -20 to 550°C
Measuring tools: Center spot, Hot spot, Cold spot
User-definable: 3 spots, 3 rectangles and 1 line
General parameters:
Wi-Fi: No
USB interface: USB-C Android, USB-C iOS, Lightning iOS (Includes a Lightning to USB-C adapter)
Battery: No
Operating time: No
Chargung time: No
Protection Level: IP40 and drop test 1m
Stogare temperature: -20°C +60°C
Weight: 20g
Dimension: 42 x 22,5 x 11,2 mm
