Apraksts
Infrared Image:
IR resolution: 640 x 480
Image Frequency: 30Hz
Detector Pitch: 17 μm
Spectral Range: 7.5 to 14 μm
FOV: 41.9 x 33.3°
IFOV: 1.13 mrad
Focus Mode: Manual Focus
Min. focus distance: 0.3m
SuperIR: Yes, 1280 x 960p
Image specification:
Camera: 3264x2448p (8Mp)
Display: 640×480, 3.5″ LCD touch screen
Digital Zoom: 1.0 to 8.0x
Image Modes: Thermal, Vsual, Fusion, Picture in Picture, Blending.
Color Palettes: White Hot, Black Hot, Rainbow, Ironbow, Red Hot, Fusion, Rain, Blue Red.
Measurement:
Temperature range: -20 to 650°C
Measuring tools: Center spot, Hot spot, Cold spot
Data Storage and file specification:
Storage Media: Memory card 64Gb
Image Storage Capacity: About 100.000 Images
Video Storage Capacity: About 300 hours
Video File Format: MP4 video and Radiometric video
General parameters:
Wi-Fi: Yes, 802.11 (2.4 and 5 GHz)
Bluetooth: Yes, 4.2v
USB interface: USB Type;C
Battery: Rechrgeable Li-ion battery.
Operating time: Appox. 6 hours
Chargung time: 4 hours
Power saving: Manual Sleep and Auto Power-off
Protection Level: IP54 and drop test 2m
Stogare temperature: -20°C +60°C
Weight: 680g
Dimension: 244 x 100 x 104 mm
