Apraksts
Infrared Image:
IR resolution: 256×192
Image Frequency: 25Hz
Detector Pitch: 12 μm
Spectral Range: 7.5 to 14 μm
FOV: 37.2 x 50°
IFOV: 3.3 mrad
Focus Mode: Focus Free
Min. focus distance: 0.3m
SuperIR: Yes
Image specification:
Visual Camera: 1600×1200 (2Mp)
Display: 480×640, 3.2″ LCD screen
Digital Zoom: –
Image Modes: Thermal, Visual, Fusion, Picture in Picture
Color Palettes: White Hot, Black Hot, Rainbow, Ironbow, Red Hot, Fusion
Measurement:
Temperature range: -20 to 550°C
Measuring tools: Center spot, Hot spot, Cold spot
Data Storage and file specification:
Storage Media: Built-in 16G eMMC
Image Storage Capacity: About 35.000 Images
General parameters:
Wi-Fi: No
USB interface: USB Type;C
Battery: Rechrgeable Li-ion battery.
Operating time: Appox. 6 hours
Chargung time: 3 hours
Protection Level: IP64 and drop test 2m
Stogare temperature: -20°C +60°C
Weight: 220g
Dimension: 221 x 73 x 123 mm
